Search found 133 matches

by Dinoswede
Thu Nov 19, 2026 3:26 pm
Forum: Technical Discussions
Topic: Hazard light system
Replies: 10
Views: 18910

Re: Hazard light system

When the Hazard lights are activated, the total power consumtion is close to 100 W, so a 16 A fuse is perfect. There is no need for an extra fuse. The original 2400 Coupe fuses specification should be as below: 2400 Coupe 001.jpg The "M fuse" is the best one to use here, according to this ...
by Dinoswede
Fri Nov 06, 2026 10:25 pm
Forum: Technical Discussions
Topic: Hazard light system
Replies: 10
Views: 18910

Re: Hazard light system

I will try to answer your questions: 1. The original blinker relay 39 shall be replaced by the new blinker/Hazard relay. The old one can be dismantled from the car. The probably most easy way is using the original blinker relay position under the dash. You then can re-use the viola/purple, and the a...
by Dinoswede
Fri Oct 30, 2026 6:34 pm
Forum: Technical Discussions
Topic: Hazard light system
Replies: 10
Views: 18910

Re: Hazard light system

As far as I can see, you are on the right track! But first, a small correction: In my wiring diagram, I seem to have made a slight mistake, mixing left and right side of the turn signal system! The light blue/black wire from the turn signal switch 85 should be connected to terminal 49L, and the ligh...
by Dinoswede
Sat Oct 24, 2026 1:29 pm
Forum: Technical Discussions
Topic: Hazard light system
Replies: 10
Views: 18910

Re: Hazard light system

You can add a 4-way Hazard function, by using a "modern" standard indicator relay from the 90´ies. For instance something like this: relä.png Note, as the Dinos have only one turn signal warning light, you must add a simple diode bridge, like in the wiring diagram below. Otherwise this typ...
by Dinoswede
Tue Jun 16, 2026 2:25 pm
Forum: Technical Discussions
Topic: Resistance case 4174137
Replies: 3
Views: 18009

Re: Resistance case 4174137

As far as I have found out, it should only be one resistor with a protection case - for the water temperature gauge - in a Dino. Maybe the one in your engine bay pic is replacing the original one? Some kind of tampering with the electric system in your Dino seems to have been done. My suggestion is ...
by Dinoswede
Tue Jun 16, 2026 12:03 pm
Forum: Technical Discussions
Topic: Resistance case 4174137
Replies: 3
Views: 18009

Re: Resistance case 4174137

This is a resistance for protecting the water temperature gauge, if the engine reaches a dangerously high temperature. At the left cylinder head, a thermal switch is located to connect the water temperature gauge fully to ground if the engine is too hot, making the needle (as a warning) point at the...
by Dinoswede
Sun Mar 08, 2026 11:49 pm
Forum: Market
Topic: Fiat Dino parts for auction 11 March 2026 in Sweden
Replies: 0
Views: 84078

Fiat Dino parts for auction 11 March 2026 in Sweden

A swedish Dino 2400 Coupe owner is selling all his collection of spare parts, new and used, and also a complete 2400 engine, a ZF gearbox and a rear differential... Everything is sold through the swedish Bilweb Auctions Company (www.bilwebauctions.se) at their auction site at 11 March 2026. It is a ...
by Dinoswede
Sun Mar 01, 2026 7:30 pm
Forum: Technical Discussions
Topic: Water temperature not working 2.0 coupe
Replies: 2
Views: 51050

Re: Water temperature not working 2.0 coupe

Yes, you are probably not aware of that the left head sender is a switch, only connecting the engine temperature gauge wire to ground when engine is dangerously hot. The gauge will then point at the red end of the scale! The sender in the right head is the "normal" sender for reading the c...
by Dinoswede
Fri Feb 13, 2026 11:58 am
Forum: Technical Discussions
Topic: Overwhelming Petrol/Exhaust Fumes
Replies: 10
Views: 83203

Re: Overwhelming Petrol/Exhaust Fumes

Not only the Dino Coupes are suffering of smell from exhaust fumes. When I first noticed the smell of exhaust fumes in my Spider´s boot, I checked the exhaust systems for leaks, but in vain. Only after a new rubber seal for the boot lid was installed, the smell was gone. Strange enough, after having...
by Dinoswede
Tue Dec 16, 2025 5:39 pm
Forum: Technical Discussions
Topic: Switch command wiring coupe 2400
Replies: 2
Views: 55370

Re: Switch command wiring coupe 2400

Your problem is best solved by using the principal schemes over the two switches 90 and 91 you already have added: By using a multimeter in Resistance mode, or - if a multimeter is not availible - by using a battery and a suitible bulb, you can determine when the contacts in a certain switch are in ...
